Especificaciones:
General
Interfaces (ports):
• 24 x 10/100/1000BASE-T PoE
• 4 x 100/1000Mbps combo
Port Standards:
• IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-FX 100 Mbps over fiber optic
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper)
• IEEE 802.3z 1000BASE-X 1 Gbps over fiber optic
• IEEE 802.3az Energy Efficient Ethernet (EEE)
• IEEE 802.3x Flow Control
• IEEE 802.3af/at compliance (for PoE ports)
Network Cables: UTP Cat. 5, Cat. 5e (100 m max.)
Duplex Mode
• Full/Half-duplex for 10/100 Mbps
• Full-duplex for 1000 Mbps
Media Interface Exchange: Auto MDI/MDIX adjustment for all twisted-pair ports
Performance
Switching Capacity: 56 Gbps
Transmission Method: Store-and-forward
MAC Address Table: 8K entries
Static MAC Addresses: 256 entries
Maximum 64 Byte Packet Forwarding Rate: 41.7 Mpps
Packet Buffer Memory: 4.1 Mbits
CPU Memory: DDR3 128 MB
Flash Memory: 32 MB
PoE
PoE Capable Ports: Ports 1 to 24
Power Budget: 193W
Physical/Environmental
Power Input: 100 to 240 V AC 50/60 Hz internal universal power supply
Maximum Power Consumption:
• 247.4 W (PoE on)
• 28.1 W (PoE off)
Standby Power Consumption: 16.6 W
Fans: 2
Dimensions _(L x W x H): 440 x 250 x 44mm
Weight: 3.75 kg
